Within this article we will take a closer look at the technical specifications of the 271S7QJMB monitor from Philips. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.
Display
Let's start with the most important component of a monitor, the display. Depending on the aspect ratio of height and width, monitors can be rather wide or square, for example. Besides the pure physical dimensions, the resolution of the display and thus the quality of the display is also decisive here. For easy comparability, however, screen sizes are usually given in inches. This unit of measurement simply compares the diagonal length from the lower left to the upper right corner of the display and is thus universally applicable. This device has a screen diagonal of 27 inches ( 68.5 cm on the diagonal). While classic CRT monitors were built with a screen ratio of 4:3, this monitor has a ratio of 1.778 : 1 (width to height). If you want to pay attention to special aesthetics or simply want to place several monitors next to each other, you should pay attention to the ratio between display and non-display. The 271S7QJMB is a monitor with a ratio of 88 % between usable and non-usable front surface. The display is a IPS panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 81 ppi. The pixel pitch is 0.311 mm. The continuous possible brightness specified by the manufacturer Philips is 250 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Philips promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the 271S7QJMB 30 khz to 83 khz. Vertically, however, the image renews at a minimum rate of 56 hz up to 76 hz. The minimum response time of the monitor is ms.
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Philips has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 20000000 : 1 of dynamic contrast ratio for the monitor 271S7QJMB cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
Philips Specifies the following dimensions for the monitor 271S7QJMB without stand/feet: 37.2 cm x 61.4 cm x 5.6 cm (HxWxD)
The size of the monitor (stand included) is 51.3 x 61.4 x 25.7 cm (HxWxD). The device weighs in total (i.e. also measured with the stand) 7.18 kg. The monitor 271S7QJMB without the stand weighs 4.87 kg. This weight reduction should be taken into account for wall or arm mounting, since monitor arms have a maximum load capacity. Speaking of weight without a stand and thus wall or table mounts. The monitor supports a Vesa mounting. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 11.5 cm. This value is always measured from the bottom edge of the screen.
Rotate, tilt and swivel
The monitor from Philips has a pivot function and can thus be rotated using the included stand. A rotation to the left is possible with up to 0 degree. To the right, the monitor can be rotated by 90 degree. The 271S7QJMB can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 175 degree. Pivoting to the right is possible up to 175 degree. Thanks to the tilt function of the 271S7QJMB monitor, the screen position can be flexibly adjusted to minimize dazzling light sources and ensure optimum visibility. The angle of inclination to the rear is 20. The monitor can be tilted forward by 5 degree.
Ports
The monitor can be connected via 1 VGA ports.
camera
This monitor does not have a camera.
Loudspeaker
The monitor from Philips has integrated speakers, for playing sounds, music or speech. The sound is emitted via 2 speakers, which are integrated into the device. Each of the built-in speakers has a contingent of 2 w power.
Features
- Flicker Free: Philips 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- The display/monitor supports Frame Rate Compensation.
Anyone who works a lot on the computer spends many hours a day in front of the screen. Excessive screen work can damage the eyes. This effect can be particularly pronounced during the darker hours and in the winter months. Many monitor manufacturers have now reacted and offer technologies and settings to reduce the blue component, which is primarily controversial. Depending on the manufacturer, these can be called "Low Blue Light", "Low Blue Light Technology", "SoftBlue" or even "Eye Saver Mode" and function differently. However, it is only important that Philips offers a technology to reduce the blue content in its monitor 271S7QJMB.
WiFi / Bluetooth
Power consumption
The average consumption figure for 271S7QJMB is 15.5 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. In ECO mode, the monitor consumes 10.9 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
The maximum height at which the monitor may be operated, according to the manufacturer's specifications, is 3.658 km. The maximum permissible ambient temperature is 40 °C during operation. Below a temperature of 0 °C , the monitor from Philips should again not be used. The humidity must not exceed 80 percent. At least, however, 20 percent humidity. The monitor may be stored at a maximum humidity of 80 percent. The minimum humidity during storage should not fall below 20 percent. The maximum storage temperature should be according to Philips 60 °C. Minimal were given by Philips -20 °C. According to the manufacturer, the monitor may be stored at a maximum height of 12.192 km.
Packaging
The monitor is packaged in a cardboard box measuring 45.8 x 69 x 25.2 cm (height x width x depth). The box together with the monitor weighs about 9.69 kg.
