Today we will look at the monitor Optix MPG27C from MSI from the year 2018. Within this article, we will first take a closer look at the most important feature of a monitor -the display-, then the design, and in the next section we will go into the features of the monitor. Of course, power consumption, certifications, connectivity and other important details will also be considered.
Display
Any multimedia content can be displayed on 27 inches ( 68.5 cm on the diagonal). The size specification of a monitor refers to the screen diagonal, which is usually specified in inches. It is only comparable to a limited extent for different formats. For example, a conventional 4:3 monitor with the same screen diagonal has 6% less width, but 13% more height and a total of 7% more surface area than a monitor in 16:10 format. Despite the difference in working area, wider monitors are better suited for consuming games or current movies, for example. It is also easier to display several documents simultaneously on widescreen monitors. So, it depends on the current use case whether the aspect ratio of 1.778 : 1 makes sense for the intended use case. The display is a VA panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 81 ppi. The pixel pitch is 0.311 mm. The continuous possible brightness specified by the manufacturer MSI is 250 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. MSI promises stable color reproduction moreover within a 178 ° vertical angle. Vertically, however, the image renews at a minimum rate of 144 hz up to 144 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte.
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 90 %. According to the manufacturer, the coverage of the SRGB color space is 115 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from MSI has a static contrast ratio of 3000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 100000000 : 1 of dynamic contrast ratio for the monitor Optix MPG27C cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
The size of the monitor (stand included) is 55.5 x 61.2 x 37.9 cm (HxWxD). The device weighs in total (i.e. also measured with the stand) 7.6 kg. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 12 cm. This value is always measured from the bottom edge of the screen.
Curved
The Optix MPG27C is a curved monitor with a curvature of 1.8 m
Rotate, tilt and swivel
The monitor from MSI cannot be rotated. The Optix MPG27C can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 40 degree. Pivoting to the right is possible up to 40 degree. It is possible to adjust the tilt angle of the monitor Optix MPG27C according to personal preference to ensure ergonomic and comfortable viewing. The angle of inclination to the rear is 20. The monitor can be tilted forward by 5 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
Features
- Flicker Free: MSI 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- AMD FreeSync: By dynamically synchronizing the refresh rate of the Optix MPG27C with the frame rate, AMD FreeSync minimizes judder and ensures smooth and enjoyable gameplay.
Anyone who works a lot on the computer spends many hours a day in front of the screen. Excessive screen work can damage the eyes. This effect can be particularly pronounced during the darker hours and in the winter months. Many monitor manufacturers have now reacted and offer technologies and settings to reduce the blue component, which is primarily controversial. Depending on the manufacturer, these can be called "Low Blue Light", "Low Blue Light Technology", "SoftBlue" or even "Eye Saver Mode" and function differently. However, it is only important that MSI offers a technology to reduce the blue content in its monitor Optix MPG27C.
WiFi / Bluetooth
Power consumption
The maximum power consumption (peak) specified for this monitor is 65 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
The maximum permissible ambient temperature is 40 °C during operation. Below a temperature of 10 °C , the monitor from MSI should again not be used. The humidity must not exceed 80 percent. At least, however, 10 percent humidity.
Packaging
Additional information
