Within this article we will take a closer look at the technical specifications of the 34WL75C monitor from LG. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.
Display
Any multimedia content can be displayed on 34 inches ( 86.3 cm on the diagonal). As already known, two monitors with different outer dimensions can have the same screen diagonal. In the case of the monitor 34WL75C , we find an aspect ratio of 2.389 to 1. This means that for every 1 pixels in height, 2.389 pixels in width are added. For comparison: A classic CRT monitor had an aspect ratio of 4:3. Approximately 91.6 % of the front surface of the monitor is taken up by the display, while the remaining part is screen edges that do not allow the image to be displayed. If you want to place several monitors next to each other, it is advisable to choose models with narrow edges. The display is a AH panel. The panel has a resolution of 3440 x 1440 px. The pixel density is 109 ppi. The pixel pitch is 0.233 mm. The continuous possible brightness specified by the manufacturer LG is 300 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. LG promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the 34WL75C 31.469 khz to 88.82 khz. Vertically, however, the image renews at a minimum rate of 56 hz up to 61 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 10 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the SRGB color space is 99 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from LG has a static contrast ratio of 1000 : 1 , according to the manufacturer.
HDR
The monitor supports all HDR modes listed here:
- HDR 10
screen design
For the installation of the monitor, a space requirement of approximately 35.9 cm in height, 81.4 cm in width and 9.2 cm in depth is to be assumed.
If you want to place the monitor described here on the desk without a wall mount, you should allow for 45.9 x 81.4 x 25 cm (HxWxD) of space. The device weighs 8 kg with the stand in place. Without stand, the monitor weighs 6.3 kg. Speaking of weight without a stand and thus wall or table mounts. The monitor supports a Vesa mounting. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 11 cm. This value is always measured from the bottom edge of the screen.
Curved
The 34WL75C is a curved monitor with a curvature of 1.8 m
Rotate, tilt and swivel
The monitor from LG cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. The monitor 34WL75C offers the option of adjusting the tilt as required to create an ergonomic working environment and reduce visual fatigue. The angle of inclination to the rear is 15. The monitor can be tilted forward by 5 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
Features
- Flicker Free: LG 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- Picture by Picture mode
- The display/monitor supports Frame Rate Compensation.
The monitor from LG supports the reduction of artifacts within dark image areas, which are caused by compression of the played video files, for example. Depending on the manufacturer, this technology is called Black Boost, Dark Boost, Black Stabilizer, Black Equalizer or Black Enhancement.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 60 w. The maximum power consumption (peak) specified for this monitor is 65 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. In ECO mode, the monitor consumes 49 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. There are 3 amps specified. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
During operation, the ambient temperature must not exceed 40 °C , to ensure full functionality. Below a temperature of 0 °C , the monitor from LG should again not be used. The humidity must not exceed 80 percent. At least, however, 10 percent humidity. The monitor may be stored at a maximum humidity of 85 percent. The minimum humidity during storage should not fall below 5 percent. The maximum storage temperature should be according to LG 60 °C. Minimal were given by LG -20 °C.
Packaging
The monitor is packaged in a cardboard box measuring 52.5 x 98.6 x 21.1 cm (height x width x depth). The box together with the monitor weighs about 11.9 kg.
