Lenovo P24q-10

Product image for P24q-10

Within this article we will take a closer look at the technical specifications of the P24q-10 monitor from Lenovo. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.

Display

Let's start with the size of the display. It is 23 inches ( 60.4 cm on the diagonal) large and should thus offer enough space for all contents according to Lenovo. The size specification of a monitor refers to the screen diagonal, which is usually specified in inches. It is only comparable to a limited extent for different formats. For example, a conventional 4:3 monitor with the same screen diagonal has 6% less width, but 13% more height and a total of 7% more surface area than a monitor in 16:10 format. Despite the difference in working area, wider monitors are better suited for consuming games or current movies, for example. It is also easier to display several documents simultaneously on widescreen monitors. So, it depends on the current use case whether the aspect ratio of 1.778 : 1 makes sense for the intended use case. Around 88.6 % of the front surface of the monitor consists of the display, while the rest is made up of screen edges that cannot display images. If you want to place several monitors next to each other, it is advisable to prefer those with narrow edges. The display is a IPS panel. The panel has a resolution of 2560 x 1440 px. The pixel density is 123 ppi. The pixel pitch is 0.206 mm. The continuous possible brightness specified by the manufacturer Lenovo is 300 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Lenovo promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the P24q-10 30 khz to 99 khz. Vertically, however, the image renews at a minimum rate of 50 hz up to 76 hz. The minimum response time of the monitor is ms. The maximum response time of the monitor is ms. The average response time of the monitor is about ms. The display panel is Anti-glare/Matte.

Color space

The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the SRGB color space is 99 %.

Contrast ratio

Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Lenovo has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 3000000 : 1 of dynamic contrast ratio for the monitor P24q-10 cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.

HDR

The monitor supports all HDR modes listed here:

screen design

For the installation of the monitor, a space requirement of approximately 32.5 cm in height, 54 cm in width and 4.2 cm in depth is to be assumed.
The size of the monitor (stand included) is 37.3 x 54 x 26.1 cm (HxWxD). As for the weight, Lenovo states a total weight of 5.6 kg with stand. A wall mount should be designed for at least 3.73 kg to hold the P24q-10 neatly and securely. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 11 cm. This value is always measured from the bottom edge of the screen.

Rotate, tilt and swivel

The monitor from Lenovo has a pivot function and can thus be rotated using the included stand. A rotation to the left is possible with up to 90 degree. To the right, the monitor can be rotated by 90 degree. The P24q-10 can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 45 degree. Pivoting to the right is possible up to 45 degree. It is possible to adjust the tilt angle of the monitor P24q-10 according to personal preference to ensure ergonomic and comfortable viewing. The angle of inclination to the rear is 30. The monitor can be tilted forward by 5 degree.

Ports

camera

This monitor does not have a camera.

Loudspeaker

Features

  • The display/monitor supports Frame Rate Compensation.

WiFi / Bluetooth

Power consumption

The average consumption was given by Lenovo as 22 w. The maximum power consumption (peak) specified for this monitor is 67 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.

Environment

The maximum height at which the monitor may be operated, according to the manufacturer's specifications, is 5 km. During operation, the ambient temperature must not exceed 45 °C , to ensure full functionality. Below a temperature of 0 °C , the monitor from Lenovo should again not be used. The humidity must not exceed 80 percent. At least, however, 10 percent humidity. The monitor may be stored at a maximum humidity of 95 percent. The minimum humidity during storage should not fall below 5 percent. The maximum storage temperature should be according to Lenovo 60 °C. Minimal were given by Lenovo -20 °C. According to the manufacturer, the monitor may be stored at a maximum height of 12.192 km.

Packaging

The monitor is packaged in a cardboard box measuring 42.2 x 63.5 x 18.8 cm (height x width x depth). The box together with the monitor weighs about 8.93 kg.

Additional information

Has at least one 3.5mm audio output jack?
Has the monitor USB 3 ports?
Number of 3.5mm audio output jacks
1
Number of USB 3 ports
1
Released in year
2017 y
