Display, power consumption, dimensions, technologies used, connections, certifications, comfort features. All these keywords can be relevant for a purchase decision, but an exact comparison is often difficult. For this reason, we will summarize as many of the mentioned specifications as possible in an understandable form in the course of this article. Let's start with the most important component of the UltraSharp U2211H from Dell.
Display
Let's start with the size of the actual display. This information is given in inches and measures the screen diagonal of the display. It can happen that displays with the same size specification have different dimensions, since square monitors, for example, can belong to the same category as a widescreen monitor. The monitor from Dell in this article has a size of 21 inches ( 54.6 cm on the diagonal). As already known, two monitors with different outer dimensions can have the same screen diagonal. In the case of the monitor UltraSharp U2211H , we find an aspect ratio of 1.778 to 1. This means that for every 1 pixels in height, 1.778 pixels in width are added. For comparison: A classic CRT monitor had an aspect ratio of 4:3. Approximately 80.7 % of the front surface of the monitor is taken up by the display, while the remaining part is screen edges that do not allow the image to be displayed. If you want to place several monitors next to each other, it is advisable to choose models with narrow edges. The display is a e panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 102 ppi. The pixel pitch is 0.248 mm. The continuous possible brightness specified by the manufacturer Dell is 250 nt. The panel is illuminated by CCFL. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Dell promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the UltraSharp U2211H 30 khz to 83 khz. Vertically, however, the image renews at a minimum rate of 56 hz up to 75 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 72 %. According to the manufacturer, the coverage of the SRGB color space is 100 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Dell has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 10000 : 1 of dynamic contrast ratio for the monitor UltraSharp U2211H cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
Without the stand, the monitor comes with a width of 51.4 cm , a height of 30.5 cm and about 6.5 cm.
The size of the UltraSharp U2211H on the desk is likely to be particularly relevant for most users. Dell specifies a space requirement of 34.7 x 51.4 x 18.4 cm (HxWxD) with the included stand. The device weighs 6.45 kg with the stand in place. A wall mount should be designed for at least 4.5 kg to hold the UltraSharp U2211H neatly and securely. Speaking of weight without a stand and thus wall or table mounts. The monitor supports a Vesa mounting. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 10 cm. This value is always measured from the bottom edge of the screen.
Rotate, tilt and swivel
The monitor from Dell has a pivot function and can thus be rotated using the included stand. A rotation to the left is possible with up to 0 degree. To the right, the monitor can be rotated by 90 degree. The UltraSharp U2211H can be swiveled when mounted on the included stand. It is possible to adjust the tilt angle of the monitor UltraSharp U2211H according to personal preference to ensure ergonomic and comfortable viewing.
Ports
The monitor can be connected via 1 VGA ports. There are 1 HDMI ports on the monitor.
camera
This monitor does not have a camera.
Loudspeaker
Features
- The display/monitor supports Frame Rate Compensation.
Panel manufacturer
Many manufacturers of monitors and TVs fall back on third-party manufacturers, such as Samsung or LG, when choosing the actual display (panel). Thus, many of the monitors have the same panel and, conversely, differ only in their design, additional functionalities, the software used and, of course, the price. Two monitors from Dell or another manufacturer with an identical panel do not necessarily have to have the same picture quality, but it is usually a first indicator for a purchase decision. The panel used here is originally from LG Display and has the model number LM215WF2-SLB1.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 26 w. The maximum power consumption (peak) specified for this monitor is 55 w. In standby mode, the device consumes approximately 1 w. In ECO mode, the monitor consumes 22 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. There are 1.5 amps specified. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
The maximum height at which the monitor may be operated, according to the manufacturer's specifications, is 4.485 km. The maximum permissible ambient temperature is 40 °C during operation. Below a temperature of 0 °C , the monitor from Dell should again not be used. The humidity must not exceed 80 percent. At least, however, 10 percent humidity. The monitor may be stored at a maximum humidity of 90 percent. The minimum humidity during storage should not fall below 5 percent. The maximum storage temperature should be according to Dell 60 °C. Minimal were given by Dell -20 °C. According to the manufacturer, the monitor may be stored at a maximum height of 12.191 km.
Packaging
Additional information
