Within this article we will take a closer look at the technical specifications of the UltraSharp UZ2715H monitor from Dell. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.
Display
Texts, videos and/or other applications can be displayed on the 27 inches ( 54.6 cm on the diagonal) of the monitor. For books or documents, a portrait format layout is usually used because the reading flow decreases as the width of the text increases. For small diagonals, screens in 4:3 format have a clear advantage because they are better suited for display due to their height. In contrast, widescreen monitors are better suited for playing video games or displaying several documents side by side, for example. Depending on the application, it should be decided individually whether the aspect ratio of 1.778 : 1 is sufficient. The display is a IPS panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 99 ppi. The pixel pitch is 0.248 mm. The continuous possible brightness specified by the manufacturer Dell is 200 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Dell promises stable color reproduction moreover within a 178 ° vertical angle. Vertically, however, the image renews at a minimum rate of 60 hz up to 60 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Dell has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 20000000 : 1 of dynamic contrast ratio for the monitor UltraSharp UZ2715H cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
The size of the UltraSharp UZ2715H on the desk is likely to be particularly relevant for most users. Dell specifies a space requirement of 45 x 52.9 x 19.3 cm (HxWxD) with the included stand. The device weighs in total (i.e. also measured with the stand) 4.24 kg.
Rotate, tilt and swivel
The monitor from Dell cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. The monitor UltraSharp UZ2715H offers the option of adjusting the tilt as required to create an ergonomic working environment and reduce visual fatigue. The angle of inclination to the rear is 29. The monitor can be tilted forward by 10 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
Features
- Flicker Free: Dell 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- The display/monitor supports Frame Rate Compensation.
WiFi / Bluetooth
Power consumption
The average consumption figure for UltraSharp UZ2715H is 32 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.5 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
The maximum height at which the monitor may be operated, according to the manufacturer's specifications, is 5 km. The maximum permissible ambient temperature is 40 °C during operation. Below a temperature of 0 °C , the monitor from Dell should again not be used. The humidity must not exceed 85 percent. At least, however, 10 percent humidity. The monitor may be stored at a maximum humidity of 93 percent. The minimum humidity during storage should not fall below 5 percent. The maximum storage temperature should be according to Dell 55 °C. Minimal were given by Dell -25 °C. According to the manufacturer, the monitor may be stored at a maximum height of 12.192 km.
Packaging
The monitor is packaged in a cardboard box measuring 47 x 56.1 x 13.6 cm (height x width x depth). The box together with the monitor weighs about 4.24 kg.
