Within this article we will take a closer look at the technical specifications of the RL2450HT monitor from BenQ. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.
Display
Games, texts, videos and/or other applications can be displayed on the monitor's 24 inches ( 61.1 cm on the diagonal). As already mentioned or known, monitors have a certain number of pixels in height and width. In most cases, this is not a 1:1 ratio, which is also the case with the monitor from BenQ. This monitor has an aspect ratio of 1.778 : 1. This means that every 1.778 pixels in width 1 pixels in height are added. Around 78.1 % of the front surface of the monitor consists of the display, while the rest is made up of screen edges that cannot display images. If you want to place several monitors next to each other, it is advisable to prefer those with narrow edges. The display is a TN panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 91 ppi. The pixel pitch is 0.277 mm. The continuous possible brightness specified by the manufacturer BenQ is 250 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 170 ° (horizontal) viewing angle. BenQ promises stable color reproduction moreover within a 160 ° vertical angle. The refresh rate is horizontally seen at the RL2450HT 30 khz to 83 khz. Vertically, however, the image renews at a minimum rate of 50 hz up to 76 hz. The minimum response time of the monitor is ms. The average response time of the monitor is about ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 72 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from BenQ has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 12000000 : 1 of dynamic contrast ratio for the monitor RL2450HT cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
BenQ Specifies the following dimensions for the monitor RL2450HT without stand/feet: 35 cm x 57.9 cm x 6.3 cm (HxWxD)
If you want to place the monitor described here on the desk without a wall mount, you should allow for 42.2 x 57.9 x 23 cm (HxWxD) of space. The device weighs 6.07 kg with the stand in place. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 11 cm. This value is always measured from the bottom edge of the screen.
Rotate, tilt and swivel
The monitor from BenQ has a pivot function and can thus be rotated using the included stand. A rotation to the left is possible with up to 0 degree. To the right, the monitor can be rotated by 90 degree. The RL2450HT can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 45 degree. Pivoting to the right is possible up to 45 degree. The monitor RL2450HT offers the option of adjusting the tilt as required to create an ergonomic working environment and reduce visual fatigue. The angle of inclination to the rear is 20. The monitor can be tilted forward by 5 degree.
Ports
The monitor can be connected via 1 VGA ports.
camera
This monitor does not have a camera.
Loudspeaker
Features
- The display/monitor supports Frame Rate Compensation.
The monitor from BenQ supports the reduction of artifacts within dark image areas, which are caused by compression of the played video files, for example. Depending on the manufacturer, this technology is called Black Boost, Dark Boost, Black Stabilizer, Black Equalizer or Black Enhancement.
Panel manufacturer
Many manufacturers of monitors and TVs fall back on third-party manufacturers, such as Samsung or LG, when choosing the actual display (panel). Thus, many of the monitors have the same panel and, conversely, differ only in their design, additional functionalities, the software used and, of course, the price. Two monitors from BenQ or another manufacturer with an identical panel do not necessarily have to have the same picture quality, but it is usually a first indicator for a purchase decision. The panel used here is originally from AU Optronics and has the model number M240HW01 V2 M240HW01 VB M240HW01 VD.
WiFi / Bluetooth
Power consumption
The average consumption was given by BenQ as 27 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
For temperature, the maximum permissible ambient temperature is 40 °C. Below a temperature of 5 °C , the monitor from BenQ should again not be used. The humidity must not exceed 90 percent. At least, however, 20 percent humidity. The monitor may be stored at a maximum humidity of 90 percent. The minimum humidity during storage should not fall below 10 percent. The maximum storage temperature should be according to BenQ 60 °C. Minimal were given by BenQ -20 °C.
Packaging
Additional information
