Today we will look at the monitor EW2770QZ from BenQ from the year 2017. Within this article, we will first take a closer look at the most important feature of a monitor -the display-, then the design, and in the next section we will go into the features of the monitor. Of course, power consumption, certifications, connectivity and other important details will also be considered.
Display
According to the manufacturer, the display measures 27 inches ( 68.4 cm on the diagonal). As already known, two monitors with different outer dimensions can have the same screen diagonal. In the case of the monitor EW2770QZ , we find an aspect ratio of 1.778 to 1. This means that for every 1 pixels in height, 1.778 pixels in width are added. For comparison: A classic CRT monitor had an aspect ratio of 4:3. Around 92.3 % of the front surface of the monitor consists of the display, while the rest is made up of screen edges that cannot display images. If you want to place several monitors next to each other, it is advisable to prefer those with narrow edges. The display is a AH3 panel. The panel has a resolution of 2560 x 1440 px. The pixel density is 109 ppi. The pixel pitch is 0.233 mm. The continuous possible brightness specified by the manufacturer BenQ is 350 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. BenQ promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the EW2770QZ 30 khz to 90 khz. Vertically, however, the image renews at a minimum rate of 50 hz up to 76 hz. The minimum response time of the monitor is ms. The average response time of the monitor is about ms. The EW2770QZ monitor impresses with its function called 'Adaptive Brightness'. This technology automatically adjusts the brightness of the screen to the lighting conditions of the current scene. This ensures a pleasant and eye-friendly display in various situations.
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 76 %. According to the manufacturer, the coverage of the SRGB color space is 100 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from BenQ has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 200000000 : 1 of dynamic contrast ratio for the monitor EW2770QZ cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
For the installation of the monitor, a space requirement of approximately 35.3 cm in height, 61.3 cm in width and 6.4 cm in depth is to be assumed.
The size of the EW2770QZ on the desk is likely to be particularly relevant for most users. BenQ specifies a space requirement of 46 x 61.3 x 19.8 cm (HxWxD) with the included stand. The device weighs in total (i.e. also measured with the stand) 5.9 kg. The monitor EW2770QZ without the stand weighs 4.46 kg. This weight reduction should be taken into account for wall or arm mounting, since monitor arms have a maximum load capacity. Speaking of weight without a stand and thus wall or table mounts. The monitor supports a Vesa mounting.
Rotate, tilt and swivel
The monitor from BenQ cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. The tilt of the monitor EW2770QZ can be individually adjusted to optimize the viewing angle and increase comfort during use. The angle of inclination to the rear is 20. The monitor can be tilted forward by 5 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
The monitor from BenQ has integrated speakers, for playing sounds, music or speech. The sound is emitted via 2 speakers, which are integrated into the device. Each of the built-in speakers has a contingent of 2 w power.
Features
- Flicker Free: BenQ 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
Anyone who works a lot on the computer spends many hours a day in front of the screen. Excessive screen work can damage the eyes. This effect can be particularly pronounced during the darker hours and in the winter months. Many monitor manufacturers have now reacted and offer technologies and settings to reduce the blue component, which is primarily controversial. Depending on the manufacturer, these can be called "Low Blue Light", "Low Blue Light Technology", "SoftBlue" or even "Eye Saver Mode" and function differently. However, it is only important that BenQ offers a technology to reduce the blue content in its monitor EW2770QZ.
Panel manufacturer
Many manufacturers of monitors and TVs fall back on third-party manufacturers, such as Samsung or LG, when choosing the actual display (panel). Thus, many of the monitors have the same panel and, conversely, differ only in their design, additional functionalities, the software used and, of course, the price. Two monitors from BenQ or another manufacturer with an identical panel do not necessarily have to have the same picture quality, but it is usually a first indicator for a purchase decision. The panel used here is originally from LG Display and has the model number LM270WQ5-SSA1.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 25 w. The maximum power consumption (peak) specified for this monitor is 45 w. In standby mode, the device consumes approximately 0.5 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
Packaging
Additional information
