Display, power consumption, dimensions, technologies used, connections, certifications, comfort features. All these keywords can be relevant for a purchase decision, but an exact comparison is often difficult. For this reason, we will summarize as many of the mentioned specifications as possible in an understandable form in the course of this article. Let's start with the most important component of the VG278HE from Asus.
Display
Any multimedia content can be displayed on 27 inches ( 68.5 cm on the diagonal). Let's keep it short and sweet. The monitor has an aspect ratio of 1.778 : 1. In addition to the aspect ratios and the specified screen diagonal, some enthusiasts may also be interested in the ratio between the monitor surface and the actual display. This ratio describes the general relationship between non-display and display. In other words, approximately 81.1 % of the front surface of the monitor consists of the display, while the rest consists of screen edges and cannot display an image. When setting up several monitors next to each other, it is advisable to give preference to models with the narrowest possible edges. The display is a TN panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 81 ppi. The pixel pitch is 0.311 mm. The continuous possible brightness specified by the manufacturer Asus is 300 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 170 ° (horizontal) viewing angle. Asus promises stable color reproduction moreover within a 160 ° vertical angle. The refresh rate is horizontally seen at the VG278HE 110 khz to 160 khz. Vertically, however, the image renews at a minimum rate of 100 hz up to 144 hz. The analog refresh rate of this monitor is 23 khz to 83 khz. The frame rate in the analogue range is vertical at the VG278HE 50 hz to 85 hz. The minimum response time of the monitor is ms. The average response time of the monitor is about ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 72 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Asus has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 50000000 : 1 of dynamic contrast ratio for the monitor VG278HE cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
Without the stand, the monitor comes with a width of 64.3 cm , a height of 38.5 cm and about 5.9 cm.
The size of the VG278HE on the desk is likely to be particularly relevant for most users. Asus specifies a space requirement of 43.7 x 64.3 x 24.9 cm (HxWxD) with the included stand. The device weighs in total (i.e. also measured with the stand) 8.2 kg. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 10 cm. This value is always measured from the bottom edge of the screen.
Rotate, tilt and swivel
The monitor from Asus cannot be rotated. The VG278HE can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 150 degree. Pivoting to the right is possible up to 150 degree. Thanks to the tilt function of the VG278HE monitor, the screen position can be flexibly adjusted to minimize dazzling light sources and ensure optimum visibility. The angle of inclination to the rear is 15. The monitor can be tilted forward by 5 degree.
Ports
The monitor can be connected via 1 VGA ports.
camera
This monitor does not have a camera.
Loudspeaker
The monitor from Asus has integrated speakers, for playing sounds, music or speech. The sound is emitted via 2 speakers, which are integrated into the device. Each of the built-in speakers has a contingent of 3 w power.
Features
- Flicker Free: Asus 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- Display of 3D content, using 3D glasses
Panel manufacturer
Many manufacturers of monitors and TVs fall back on third-party manufacturers, such as Samsung or LG, when choosing the actual display (panel). Thus, many of the monitors have the same panel and, conversely, differ only in their design, additional functionalities, the software used and, of course, the price. Two monitors from Asus or another manufacturer with an identical panel do not necessarily have to have the same picture quality, but it is usually a first indicator for a purchase decision. The panel used here is originally from Innolux and has the model number M270HHF-L10.
WiFi / Bluetooth
Power consumption
The average consumption was given by Asus as 29.5 w. The maximum power consumption (peak) specified for this monitor is 50 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.5 w. In ECO mode, the monitor consumes 15 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
For temperature, the maximum permissible ambient temperature is 50 °C. Below a temperature of 0 °C , the monitor from Asus should again not be used. The maximum storage temperature should be according to Asus 60 °C. Minimal were given by Asus 20 °C.
Packaging
Additional information
