Within this article we will take a closer look at the technical specifications of the VA209N monitor from Asus. For this we will talk about all possible categories that could be relevant. To start with, we will look at the display, talk about the design and in the next section we will go into the features of the monitor. Other features such as power consumption, connectors and certifications will follow later in the text.
Display
Videos and/or other applications can be displayed on the monitor's 19 inches ( 49.4 cm on the diagonal). Let's keep it short and sweet. The monitor has an aspect ratio of 1.6 : 1. The display is a IPS panel. The panel has a resolution of 1440 x 900 px. The pixel density is 87 ppi. The pixel pitch is 0.291 mm. The continuous possible brightness specified by the manufacturer Asus is 250 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Asus promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the VA209N 24 khz to 83 khz. Vertically, however, the image renews at a minimum rate of 55 hz up to 76 hz. The analog refresh rate of this monitor is 24 khz to 83 khz. The frame rate in the analogue range is vertical at the VA209N 55 hz to 76 hz. The average response time of the monitor is about ms. The display panel is Anti-glare/Matte.
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 72 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Asus has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 80000000 : 1 of dynamic contrast ratio for the monitor VA209N cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
If you want to place the monitor described here on the desk without a wall mount, you should allow for 37.6 x 45.4 x 18.9 cm (HxWxD) of space. The device weighs 2.6 kg with the stand in place.
Rotate, tilt and swivel
The monitor from Asus cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. It is possible to adjust the tilt angle of the monitor VA209N according to personal preference to ensure ergonomic and comfortable viewing. The angle of inclination to the rear is 20. The monitor can be tilted forward by 5 degree.
Ports
The monitor can be connected via 1 VGA ports.
camera
This monitor does not have a camera.
Loudspeaker
Features
- Flicker Free: Asus 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
Anyone who works a lot on the computer spends many hours a day in front of the screen. Excessive screen work can damage the eyes. This effect can be particularly pronounced during the darker hours and in the winter months. Many monitor manufacturers have now reacted and offer technologies and settings to reduce the blue component, which is primarily controversial. Depending on the manufacturer, these can be called "Low Blue Light", "Low Blue Light Technology", "SoftBlue" or even "Eye Saver Mode" and function differently. However, it is only important that Asus offers a technology to reduce the blue content in its monitor VA209N. Game mode allows you to enjoy an enhanced gaming experience on your monitor. This mode can combine different settings on your monitor to provide a better picture and therefore an improved gaming experience.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 25 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.5 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
During operation, the ambient temperature must not exceed 40 °C , to ensure full functionality. Below a temperature of 0 °C , the monitor from Asus should again not be used. The maximum storage temperature should be according to Asus 60 °C. Minimal were given by Asus -20 °C.
Packaging
Additional information
