Display, power consumption, dimensions, technologies used, connections, certifications, comfort features. All these keywords can be relevant for a purchase decision, but an exact comparison is often difficult. For this reason, we will summarize as many of the mentioned specifications as possible in an understandable form in the course of this article. Let's start with the most important component of the PA27UCX from Asus.
Display
According to the manufacturer, the display measures 27 inches ( 68.5 cm on the diagonal). The size specification of a monitor refers to the screen diagonal, which is usually specified in inches. It is only comparable to a limited extent for different formats. For example, a conventional 4:3 monitor with the same screen diagonal has 6% less width, but 13% more height and a total of 7% more surface area than a monitor in 16:10 format. Despite the difference in working area, wider monitors are better suited for consuming games or current movies, for example. It is also easier to display several documents simultaneously on widescreen monitors. So, it depends on the current use case whether the aspect ratio of 1.778 : 1 makes sense for the intended use case. Approximately 87.2 % of the front surface of the monitor is taken up by the display, while the remaining part is screen edges that do not allow the image to be displayed. If you want to place several monitors next to each other, it is advisable to choose models with narrow edges. The display is a AHVA panel. The panel has a resolution of 3840 x 2160 px. The pixel density is 163 ppi. The pixel pitch is 0.155 mm. The monitor's panel has a maximum brightness of 1000 nt. A high peak brightness enables a particularly clear and well visible display of content on the screen. The panel is illuminated by Mini LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Asus promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the PA27UCX 40 khz to 144 khz. Vertically, however, the image renews at a minimum rate of 30 hz up to 60 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 10 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. The coverage of the Adobe RGB 1998 color space is 99 % according to the manufacturer. According to the manufacturer, the coverage of the DCI-P3 color space is 97 %. According to the manufacturer, the coverage of the SRGB color space is 100 %. The REC 2020 color space is covered to 83 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Asus has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 1000000 : 1 of dynamic contrast ratio for the monitor PA27UCX cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
- HDR 10
- HDR 1000
- HDR HLG
- Dolby Vision
screen design
For the installation of the monitor, a space requirement of approximately 36.7 cm in height, 62.5 cm in width and 9.1 cm in depth is to be assumed.
The size of the PA27UCX on the desk is likely to be particularly relevant for most users. Asus specifies a space requirement of 42.4 x 62.5 x 22.8 cm (HxWxD) with the included stand. The device weighs in total (i.e. also measured with the stand) 11.5 kg. Without stand, the monitor weighs 7.6 kg. Speaking of weight without a stand and thus wall or table mounts. The monitor supports a Vesa mounting. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 12 cm. This value is always measured from the bottom edge of the screen.
Rotate, tilt and swivel
The monitor from Asus has a pivot function and can thus be rotated using the included stand. A rotation to the left is possible with up to 90 degree. To the right, the monitor can be rotated by 90 degree. The PA27UCX can be swiveled when mounted on the included stand. Pivoting to the left is possible up to 60 degree. Pivoting to the right is possible up to 60 degree. The tilt of the monitor PA27UCX can be individually adjusted to optimize the viewing angle and increase comfort during use. The angle of inclination to the rear is 23. The monitor can be tilted forward by 5 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
The monitor from Asus has integrated speakers, for playing sounds, music or speech. The sound is emitted via 2 speakers, which are integrated into the device. Each of the built-in speakers has a contingent of 2 w power.
Features
- Flicker Free: Asus 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- Picture by Picture mode
- Picture in Picture mode
Anyone who works a lot on the computer spends many hours a day in front of the screen. Excessive screen work can damage the eyes. This effect can be particularly pronounced during the darker hours and in the winter months. Many monitor manufacturers have now reacted and offer technologies and settings to reduce the blue component, which is primarily controversial. Depending on the manufacturer, these can be called "Low Blue Light", "Low Blue Light Technology", "SoftBlue" or even "Eye Saver Mode" and function differently. However, it is only important that Asus offers a technology to reduce the blue content in its monitor PA27UCX. The Adaptive Sync feature of the PA27UCX dynamically varies the monitor's refresh rate and responds to the game's required frame rates.
WiFi / Bluetooth
Power consumption
The average consumption was given by Asus as 46 w. In standby mode, the device consumes approximately 0.5 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
For temperature, the maximum permissible ambient temperature is 40 °C. Below a temperature of 0 °C , the monitor from Asus should again not be used. The maximum storage temperature should be according to Asus 60 °C. Minimal were given by Asus -20 °C.
Packaging
The monitor is packaged in a cardboard box measuring 47.9 x 76.8 x 35.5 cm (height x width x depth). The box together with the monitor weighs about 15.5 kg.
