Display, power consumption, dimensions, technologies used, connections, certifications, comfort features. All these keywords can be relevant for a purchase decision, but an exact comparison is often difficult. For this reason, we will summarize as many of the mentioned specifications as possible in an understandable form in the course of this article. Let's start with the most important component of the I2281FWH from AOC.
Display
21 inches ( 54.6 cm on the diagonal) offer sufficient space for texts in any office applications, for example. While classic CRT monitors were built with a screen ratio of 4:3, this monitor has a ratio of 1.778 : 1 (width to height). The display is a AH panel. The panel has a resolution of 1920 x 1080 px. The pixel density is 102 ppi. The pixel pitch is 0.248 mm. The continuous possible brightness specified by the manufacturer AOC is 250 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. AOC promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the I2281FWH 30 khz to 83 khz. Vertically, however, the image renews at a minimum rate of 50 hz up to 76 hz. The minimum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 8 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from AOC has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 50000000 : 1 of dynamic contrast ratio for the monitor I2281FWH cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
If you want to place the monitor described here on the desk without a wall mount, you should allow for 40.5 x 53.1 x 12.8 cm (HxWxD) of space. The device weighs 2.65 kg with the stand in place.
Rotate, tilt and swivel
The monitor from AOC cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. The monitor I2281FWH can be tilted. The angle of inclination to the rear is 20. The monitor can be tilted forward by 3 degree.
Ports
The monitor can be connected via 1 VGA ports.
camera
This monitor does not have a camera.
Loudspeaker
Features
- Flicker Free: AOC 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- The display/monitor supports Frame Rate Compensation.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 20 w. The maximum power consumption (peak) specified for this monitor is 25 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.3 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. There are 1.31 amps specified. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
The maximum height at which the monitor may be operated, according to the manufacturer's specifications, is 5 km. During operation, the ambient temperature must not exceed 40 °C , to ensure full functionality. Below a temperature of 0 °C , the monitor from AOC should again not be used. The humidity must not exceed 85 percent. At least, however, 10 percent humidity. The monitor may be stored at a maximum humidity of 93 percent. The minimum humidity during storage should not fall below 5 percent. The maximum storage temperature should be according to AOC 55 °C. Minimal were given by AOC -25 °C. According to the manufacturer, the monitor may be stored at a maximum height of 12.192 km.
Packaging
The monitor is packaged in a cardboard box measuring 45.2 x 56 x 18.5 cm (height x width x depth). The box together with the monitor weighs about 4.3 kg.
