Today we will look at the monitor XR341CK from Acer from the year 2015. Within this article, we will first take a closer look at the most important feature of a monitor -the display-, then the design, and in the next section we will go into the features of the monitor. Of course, power consumption, certifications, connectivity and other important details will also be considered.
Display
Videos and/or other applications can be displayed on the monitor's 34 inches ( 86.3 cm on the diagonal). Television screens and monitors usually have an aspect ratio of 16:9 (approximately 1.78:1). More rarely, computer monitors are also found with an aspect ratio of 16:10.
Ultrawidemonitors are often manufactured with an aspect ratio of 21:9 (approximately 2.34:1). They are mainly used for computer games and as an alternative to two side-by-side screens. The first devices of this type came onto the market around 2014. Against this backdrop, the monitor XR341CK from Acer faces an aspect ratio of 2.389 : 1. In addition to the aspect ratios and the specified screen diagonal, the ratio between the monitor surface and the actual display could also be important for some enthusiasts. This ratio describes the general relationship between the non-display area and the display. In other words, approximately 86.2 % of the front surface of the monitor consists of the display, while the remaining percent consists of screen edges and does not enable image reproduction. When setting up several monitors next to each other, it is advisable to prefer models with the narrowest possible edges. The display is a AH panel. The panel has a resolution of 3440 x 1440 px. The pixel density is 109 ppi. The pixel pitch is 0.233 mm. The continuous possible brightness specified by the manufacturer Acer is 300 nt. The panel is illuminated by W-LED. The built-in panel ensures stable color reproduction of the image, even at deviating viewing angles, by means of its 178 ° (horizontal) viewing angle. Acer promises stable color reproduction moreover within a 178 ° vertical angle. The refresh rate is horizontally seen at the XR341CK 112 khz to 112 khz. Vertically, however, the image renews at a minimum rate of 30 hz up to 75 hz. The minimum response time of the monitor is ms. The maximum response time of the monitor is ms. The display panel is Anti-glare/Matte (3H).
Color space
The panel has a bit depth of 10 per color channel, but what does that mean? The number of bits determines how many colors can be encoded for the individual pixels of the display. For an 8-bit panel, for example, this is 256 different colors (2^8 = 256). However, since we usually display three different colors per pixel at the same time, in theory about 16 million (256^3) different colors are possible by mixing the three pixels. A 10-bit panel could even display a billion colors. According to the manufacturer, the coverage of the NTSC 1953 color space is 72 %. According to the manufacturer, the coverage of the SRGB color space is 100 %.
Contrast ratio
Contrast ratio is a common measurement used to represent the maximum relative differences in brightness between black and white. It describes the ability of a screen or projector to produce a high-contrast image and is the quotient of the maximum and minimum displayable luminance. The higher the values are away from each other, the stronger the quantitatively seen difference between black and white is set up, which in turn results in an improved image quality. This monitor from Acer has a static contrast ratio of 1000 : 1 , according to the manufacturer. In contrast to the static contrast ratio, the dynamic contrast ratio changes the brightness of the panel itself in addition to the difference measurement from black to white. In addition to the difference between the brightest and the darkest pixel, the backlight is thus changed. Since the brightness of the panel may not be able to be adjusted exactly to a single pixel, a so-called halo effect is possible. The value of 100000000 : 1 of dynamic contrast ratio for the monitor XR341CK cannot provide any information about the severity of the halo effect here. Therefore, it is more useful to compare the static contrast ratio.
HDR
The monitor supports all HDR modes listed here:
screen design
For the installation of the monitor, a space requirement of approximately 37.5 cm in height, 82.5 cm in width and 9.9 cm in depth is to be assumed.
If you want to place the monitor described here on the desk without a wall mount, you should allow for 58.6 x 82.5 x 30.9 cm (HxWxD) of space. The device weighs 9.9 kg with the stand in place. A height-adjustable stand ensures an improved ergonomic posture during use. The monitor can be moved to a maximum height of 13 cm. This value is always measured from the bottom edge of the screen.
Curved
The XR341CK is a curved monitor with a curvature of 3.8 m
Rotate, tilt and swivel
The monitor from Acer cannot be rotated. The monitor cannot be swiveled. This feature could be retrofitted with a third-party stand. The tilt of the monitor XR341CK can be individually adjusted to optimize the viewing angle and increase comfort during use. The angle of inclination to the rear is 35. The monitor can be tilted forward by 5 degree.
Ports
camera
This monitor does not have a camera.
Loudspeaker
The monitor from Acer has integrated speakers, for playing sounds, music or speech. The sound is emitted via 2 speakers, which are integrated into the device. Each of the built-in speakers has a contingent of 7 w power.
Features
- Flicker Free: Acer 's Flicker Free technology minimizes distracting screen flicker, allowing you to work and/or play longer without restrictions.
- AMD FreeSync: By dynamically synchronizing the refresh rate of the XR341CK with the frame rate, AMD FreeSync minimizes judder and ensures smooth and enjoyable gameplay.
- Picture by Picture mode
- Picture in Picture mode
- The display/monitor supports Frame Rate Compensation.
Panel manufacturer
Many manufacturers of monitors and TVs fall back on third-party manufacturers, such as Samsung or LG, when choosing the actual display (panel). Thus, many of the monitors have the same panel and, conversely, differ only in their design, additional functionalities, the software used and, of course, the price. Two monitors from Acer or another manufacturer with an identical panel do not necessarily have to have the same picture quality, but it is usually a first indicator for a purchase decision. The panel used here is originally from LG Display and has the model number LM340UW2-SSA1.
WiFi / Bluetooth
Power consumption
On average, the monitor consumes approximately 49 w. The maximum power consumption (peak) specified for this monitor is 57 w. In standby mode, the device consumes approximately 0.5 w. When switched off, on the other hand, the monitor consumes only 0.4 w. In ECO mode, the monitor consumes 42.5 w. The monitor can be operated on a 110v power supply. The monitor can be operated on a 220v power supply. The power grid has to supply a frequency of 50 hz to 60 hz.
Environment
During operation, the ambient temperature must not exceed 35 °C , to ensure full functionality. Below a temperature of 5 °C , the monitor from Acer should again not be used. The humidity must not exceed 85 percent. At least, however, 10 percent humidity. The maximum storage temperature should be according to Acer 60 °C. Minimal were given by Acer -20 °C.
Packaging
Additional information
